| Basic parameters |
Model |
RE-501 |
| |
Glass Material |
GG-17 |
| Bracket Material |
Stainless steel |
| Material of pot shell |
Spraying anticorrosion
310*320*240mm |
| Material of Pan gallbladder |
Stainless steel
280*170mm |
| plate size |
350*330mm |
| Rotating bottle volume |
5L ￠50Flange mouth |
| Collect bottle volume |
3L 35#Ball mill |
| vacuum degree |
0.098Mpa |
| Rotating power |
40W |
| Rotating speed |
0-120rpm |
| heating power |
2KW |
| Temperature of bath |
0-400°C control, 0~180°C heating |
| Rotating bottle volume |
±1°C |
| Voltage (V/Hz) |
220V/50Hz |
| Lifting trip |
150mm |
| Shape size(mm) |
700*335*1009mm |
| Packing dimensions(mm) |
1040*620*410 0.26square |
| Packing weight (KG) |
38 |
Function
Configuration |
Speed regulation mode |
e-cvt |
| Speed display mode |
digital display |
| Temperature display mode |
KType 1 sensordigital display |
| temperature control |
Intelligent Temperature Control |
| Sealing method |
Tetrafluoro Component Sealing |
| condenser |
Vertical condenser100*590mm |
| Lifting mode |
Manual lifting of bathtub |
| Continuous Feeds |
19#Label feeding valve |
| Discharge square |
Tetrafluoride discharge valve
￠50Flange mouth |
| Vacuum display mode |
Vacuum meter |
